2.67 x 7/8″ Corrugated Panel
The 7/8” Corrugated Panel is an exposed fastening Metal Roofing & Siding panel. This time tested panel offers the versatility of being used in both vertical and horizontal applications. It is also known for its incredible strength and longevity. This Corrugated Roofing & Siding panel gives the look of an old time or modern look to most any application. This is commonly used in 22ga Steel, but is available in 24ga, 26ga Steel, Copper & Aluminum with many finishes including Painted Metal to Weathering Steel A606-4 (Corten).
Highlights
- Highest Quality Materials Used
- Rib Spacing is 2.67” on center
- Rib Height is ⅞”
- Panel Coverage Width is 32” for Roof Application and 34” for Wall Application
- Minimum pitch recommended 3:12
- Up to 40 Year Limited Paint Warranty Available
- Please refer to ⅞” Corrugated Panel Highlights Section to see all finishes and gauges available.
- Please refer to ⅞” Corrugated Panel Highlights for Specifications.
Details
Industry Uses
Residential
Post Frame
Agricultural
Light Commercial
Commercial
Industrial
Applications
Roofing
Siding
Interior
Soffit (non-vented)
Fascia
Fencing
Features
Rib Height: 7/8″
Rib Spacing: 2.67″ on Center
Coverage: Various Widths
Recommended Minimum Slope 3:12 Pitch
Installation
Exposed Fastening System
Solid Substrate
Open Purlin System up to 60″ span (check load restrictions)
Gauges Available
Standard Gauge(s): 26ga
Optional Gauge(s): 24ga, 22ga
Panel Lengths
1′ to 63’0″
Standard Finish
SMP (Siliconized Modified Polyester)
Optional Finishes
Kynar 500®/Hylar 5000®/PVDF
Kynar 500®/Hylar 5000®/PVDF Metallic
Galvalume®
Galvanized
Cold Rolled
Bonderized
Warranties
SMP up to 40 year Paint Warranty*
Kynar 500® up to 35 year Paint Warranty*
Color Selection
Grade 50 Standard 22ga
Non Painted
Grade 50 Standard 22ga Select
Grade 50 Standard 24ga
Economy
Grade 50 Standard 24ga Select
Grade 50 Standard 24ga Low Gloss
-
-
-
-
Gloss Black
-
Rawhide 26ga
Select Rawhide Finishes
Grade 50 Standard 26ga
Non-Painted
Premium
Download Center
Product Info
Accessories
Under X Underlayment
Fasteners (Metal to Wood)
#10 HWH 1/4″ Micro-Bit KiwikSeal WoodBinder
#10 CHWH 5/16″ Micro-Bit ZXL WoodBinder
CHWH 5/16″ Micro-Bit ZXL WoodBinder
Closures & Venting
Pipe Flashings
Sealants & Tapes
