2.75 x 3/8″ Corrugated Panel
The 3/8” Corrugated Panel is an exposed fastener Metal Roofing – Steel Roofing and/or Metal Siding – Steel Siding panel. This panel offers the versatility of being used in both vertical and horizontal applications. This Corrugated Roofing – Corrugated Siding panel gives the look of an old time and/or modern roofing application.
Highlights
- Highest Quality Materials Used
- Rib Spacing is 2.75” on center
- Rib Height is 3/8” on 2.75” Centers
- Variable Coverage (dependent on material used and/or if used for roofing or siding.)
- 1:12 Pitch or greater with butyl tape sealant & recommended self-adhered underlayment covering entire substrate 3:12 Pitch or greater (optional: recommended butyl tape sealant)
- Up to 40 Year Limited Paint Warranty Available
Details
Industry Uses
Residential
Post Frame
Agricultural
Light Commercial
Commercial
Industrial
Applications
Roofing
Wall
Interior
Soffit (non-vented)
Fascia
Ceiling
Features
Rib Height 3/8″
Rib Spacing 2.75″
Variable Coverage
Installation
Exposed Fastening System
Solid Substrate
Open Purlin System up to 60″ span (check load restrictions)
Gauges Available
Standard Gauge(s): 26ga
Panel Lengths
1″ to 63’0″
Standard Finish
SMP (Siliconized Modified Polyester)
Optional Finishes
Galvalume®
Galvanized
Warranties
SMP up to 40 year Paint Warranty*
Color Selection
Grade 80 Standard 26ga
Non-Painted
Premium
Low Gloss
-
Gloss Black
-
-
-
-
Download Center
Product Info
Accessories
Under X Underlayment
Fasteners (Metal to Wood)
#10 HWH 1/4″ Micro-Bit KiwikSeal WoodBinder
#10 CHWH 5/16″ Micro-Bit ZXL WoodBinder#10
CHWH 5/16″ Micro-Bit ZXL WoodBinder
Closures & Venting
Pipe Flashings
Sealants & Tapes
