PBR Panel

PBR (Purlin Bearing Rib) Structural Panels are one of the toughest and most economical commercial panels available. PBR Panels were designed for low pitched roofing (as low as 1/2:12 pitch – using proper butyl caulk Sealant) to steep pitched roofing.  PBR Metal Roofing – Steel Roofing Panels can span open purlins up to 60″ or be installed on a solid substrate.  PBR Panels are ideal for Agricultural and Commercial Building Projects of all types, including but not limited to: Roofing, Walls, Pole Barns, Shops, Barns, Steel Buildings, Interior Wall Panels and Fencing.  Our standard color offering uses Grade 80 High Tensile Steel for extreme strength and has a Galvalume® substrate and SMP (Silicone Modified Polyester) paint with an available 40 Year Limited Warranty.

Highlights

  • Highest Quality Materials Used
  • Proven Reliability and Strength
  • Easy Installation
  • Exposed Fasteners
  • Open Purlin System up to 60″ span (check load restrictions)
  • Up to 40 Year Paint Warranty Available
  • SMP High Tensile 26ga Grade 80 Steel (80,000ksi)(Siliconized Modified Polyester Paint)
  • Kynar 500®/Hylar 5000®/PVDF Painted Steel Available in 26ga & 24ga Grade 50 Steel (50,000ksi)
  • Manufactured in Rigby, Idaho
  • Please refer to PBR Structural Panel Details Section to see all finishes and gauges available.
  • Please refer to PBR Structural Panel Details Section for Specifications.



Details

Industry Uses

Residential

Post Frame

Agricultural

Light Commercial

Commercial

Industrial



Applications

Roofing

Siding

Interior

Soffit (non-vented)

Fascia

Fencing



Features

Rib Height 1 1/4″

Rib Spacing 12″ on Center

Coverage 36″ wide

Recommended Minimum Slope 1/2:12 Pitch (using proper butyl caulk)



Installation

Exposed Fastening System

Solid Substrate

Open Purlin System up to 60″ span (check load restrictions)



Gauges Available

Standard Gauge(s): 26ga

Optional Gauge(s): 24ga, 22ga (22ga is Perforated Galvanized Only)



Panel Lengths

2’4″ to 63’0″



Standard Finish

SMP (Siliconized Modified Polyester)



Optional Finishes

Kynar 500®/Hylar 5000®/PVDF

Kynar 500®/Hylar 5000®/PVDF Metallic

Galvalume®

Galvanized

Cold Rolled

Bonderized

Perforated Galvanized



Warranties

SMP up to 40 year Paint Warranty*

Kynar 500® up to 35 year Paint Warranty



Color Selection

Grade 50 Standard 22ga





Non Painted



Grade 50 Standard 22ga Select
Grade 50 Standard 24ga Select
Grade 50 Standard 24ga Low Gloss



Rawhide 26ga



Select Rawhide Finishes



Grade 50 Standard 26ga
