7.2 Panel
The 7.2 Panel has become one of the newest sensations in the commercial industry. It has a very robust look yet very clean lines. This panel not only looks robust, it is incredibly strong. This panel is primarily used in commercial applications but can also be used for, residential & industrial applications. Up to a 35 year limited paint warranty is available, and is available in many colors.
Highlights
- Highest Quality Materials Used
- Proven Reliability and Strength
- Rib Spacing – 7.2” on center
- Rib Height – 1 1/2”
- 36” Coverage Width allowing for Easy Installation
- Exposed Fasteners
- Paint Warranty Available
- Please refer to 7.2 Panel Details Section to see all finishes and gauges available.
- Please refer to 7.2 Panel Details Section for Specifications.
Details
Industry Uses
Residential
Post Frame
Agricultural
Light Commercial
Commercial
Industrial
Applications
Roofing
Siding
Interior
Soffit (non-vented)
Fascia
Fencing
Features
Rib Height 1 1/2″
Rib Spacing 7.2″ on Center
Coverage 36″ wide
Recommended Minimum Slope 1/2:12 Pitch (using proper butyl caulk)
Installation
Exposed Fastening System
Solid Substrate
Open Purlin System up to 60″ span (check load restrictions)
Gauges Available
Standard Gauge(s): 24ga
Optional Gauge(s): 29, 26ga, 22ga
Panel Lengths
2’4″ to 63’0″
Standard Finish
Signature® 300
Optional Finishes
Galvalume Plus®
Signature® 200
Signature® 300 Metallic
Warranties
Color Selection
Grade 50 Standard 22ga
Non Painted
Grade 50 Standard 22ga Select
Grade 50 Standard 24ga
Economy
Grade 50 Standard 24ga Select
Download Center
Product Info
Accessories
Under X Underlayment
Fasteners (Metal to Wood)
#10 HWH 1/4″ Micro-Bit KiwikSeal WoodBinder
#10 CHWH 5/16″ Micro-Bit ZXL WoodBinder#10
CHWH 5/16″ Micro-Bit ZXL WoodBinder
Closures & Venting
Pipe Flashings
Sealants & Tapes
Novaflex Metal Roofing Sealant
Coil & Flat Panel
