PBU Panel
PBU Panel is a unique panel that offers a clean look. This panel is common in commercial applications but can also be used for residential and industrial applications. Many colors available.
Highlights
- Highest Quality Materials Used
- Proven Reliability and Strength
- Rib Spacing – 6” on center
- Rib Height – ¾”
- 36” Coverage Width allowing for Easy Installation
- Exposed Fasteners
- Recommended Minimum Slope 1:12 Pitch
- Butyl Tape is required at panel side laps and end laps
- Up to 40 Year Limited Paint Warranty Available
- Please refer to PBU Panel Details Section to see all finishes and gauges available.
- Please refer to PBU Panel Details Section for Specifications.
Details
Industry Uses
Residential
Post Frame
Agricultural
Light Commercial
Commercial
Industrial
Applications
Roofing
Siding
Interior
Soffit (non-vented)
Fascia
Fencing
Features
Rib Height 3/4″
Rib Spacing 6″ on Center
Coverage 36″ wide
Recommended Minimum Slope 1:12 Pitch (using proper butyl caulk)
Installation
Exposed Fastening System
Solid Substrate
Open Purlin System up to 60″ span (check load restrictions)
Gauges Available
Standard Gauge(s): 26ga
Optional Gauge(s): 29, 24ga, 22ga
Panel Lengths
2’4″ to 63’0″
Standard Finish
Signature® 200
Optional Finishes
Galvalume Plus®
Signature® 300
Warranties
Color Selection
Standard Colors
Download Center
Product Info
Accessories
Under X Underlayment
Fasteners (Metal to Wood)
#10 HWH 1/4″ Micro-Bit KiwikSeal WoodBinder
#10 CHWH 5/16″ Micro-Bit ZXL WoodBinder#10
CHWH 5/16″ Micro-Bit ZXL WoodBinder
Closures & Venting
Pipe Flashings
Sealants & Tapes
