24″ Delta Rib Panel

The Delta Rib Panel is an exposed fastener Metal Roofing – Steel Roofing and/or Metal Siding – Steel Siding panel.  The sleek line and low profile make this Corrugated Roofing Panel desirable. The Delta Rib Panel is ideal for Residential, Agricultural and Light Commercial building projects of all types, including but not limited to:  Roofing, Walls, Pole Barns, Shops, Barns, Interior Walls for Steel Buildings, and Fencing.



Highlights

    • Highest Quality Materials Used
    • Proven Reliability and Strength
    • Exposed Fasteners
    • 3/4″ Rib Height
    • 24″ Coverage
    • Anti-Siphon sidelap design
    • Up to 40 Year Limited Paint Warranty Available
    • Please refer to Delta Rib Details Section to see all finishes and gauges available.
    • Please refer to Delta Rib Details Section for Specifications.

    Details

    Industry Uses

    Residential

    Post Frame

    Agricultural

    Light Commercial

    Commercial

    Industrial



    Applications

    Roofing

    Siding

    Interior

    Soffit (non-vented)

    Fascia

    Fencing



    Features

    Rib Height 3/4″

    Rib Spacing 8″ on Center

    Coverage 24″ wide

    Recommended Minimum Slope 3:12 Pitch



    Installation

    Exposed Fastening System

    Solid Substrate



    Gauges Available

    Standard Gauge(s): 29ga



    Panel Lengths

    Custom cut to lengths up to 40’0″



    Standard Finish

    SMP (Siliconized Modified Polyester)



    Optional Finishes

    Galvalume®



    Warranties

    SMP up to 40 year Paint Warranty*

    Color Selection

    Download Center

    Product Info

    Speaak to our Customer Service Reps for more info

    Warranty Info
    Technical Info (TIS)
