Sure Lock ML200 Double Lock
The Sure Lock ML200 HD™ is a 2” Mechanical Lock Structural Standing Seam Panel Metal Roof Panel that has all fasteners concealed for a sleek look and most importantly incredible strength and weather resistance. This Metal Roofing Panel provides a traditional look and utilizes mechanical seaming to enhance design needs. The 2” Mechanical Double Lock Panel can be installed using a expansion/floating or fixed clip system. This panel is ideal for low slopes, wide spans and open purlin systems. This panel can be single or double locked and is available in a variety of standard widths and colors, but can be customized to the needs that you are looking for. This panel can be rollformed on-site or at our facility in Rigby, Idaho. Rollforming on-site can help reduce shipping costs and damage to the panels in the shipping process.
Highlights
- Highest Quality Materials Used
- Proven Reliability and Strength
- Concealed Fasteners
- Custom Widths available from 9″ to 18″
- Recommended Minimum Slope 1/4:12 Pitch w/ Butyl; 3/4:12 w/out Butyl
- Incredible Wind Resistance using 18ga Clips
- With or Without Striations, Pencil Ribs or Box Ribs
- Protective Film can be applied prior to rollforming for added protection.
- An optional Hot Melt In-seam Sealant is available.
- Requires a seamer for installation.
- Up to 40 Year Limited Paint Warranty Available
- Watertight Warranty Available.
- Kynar 500®/Hylar 5000®/PVDF Painted Steel Available in 26ga & 24ga, 22ga Grade 50 (50,000psi)
- Manufactured in Rigby, Idaho or on Job Site
- Please refer to 2” Sure Lock ML200 HD Panel Details Section to see optional finishes and gauges available.
- Please refer to 2″ Sure Lock ML200 HD Panel Details Section for Specifications.
- Oil Canning is not cause for rejection.
Details
Color Selection
Grade 50 Standard 22ga
-
Bone White
-
-
Sandstone
-
Low Gloss Slate Gray
-
Low Gloss Charcoal Gray
-
-
-
Mansard Brown
-
22g Medium Bronze
-
-
Non Painted
Select Colors
-
22g Polar White
-
Dove Gray
-
Surrey Biege
-
Rustic Red
-
Sherwood Green
-
Dark Green
-
Regal Blue
-
Bright Silver
Grade 50 Standard 24ga
-
Stone White
-
Bone White
-
Bright White
-
Almond
-
-
Sierra Tan
-
Slate Gray
-
Musket Gray
-
-
Cityscape
-
-
-
-
Mansard Brown
-
Medium Bronze
-
-
-
Burnished Slate
-
Burgundy
-
Regal Red
-
Colonial Red
-
Terra Cotta
-
-
Classic Green
-
-
-
-
Royal Blue
Economy
Select Colors
Low Gloss Colors
-
Low Gloss Burnished Slate
-
Low Gloss Charcoal Gray
-
Low Gloss Slate Gray
-
Low Gloss Dark Bronze
Grade 50 Standard 26ga
-
Bone White
-
-
Antique Ivory
-
Ash Gray
-
Sierra Tan
-
Slate Gray
-
Musket Gray
-
Pebble Clay
-
Charcoal Gray
-
Deep Black
-
Matte Black
-
Mansard Brown
-
Medium Bronze
-
Dark Bronze
-
Burnished Slate
-
Burgundy
-
Colonial Red
-
Regal Red
-
Terra Cotta
-
Hartford Green
-
Classic Green
-
Slate Blue
-
Copper Penny
Non-Painted
Rawhide 26ga
Select Rawhide Finishes
-
Rustic Rawhide®
Premium Finish
Specialty Color
-
Galv-Ten® Raw
-
Brushed Sterling
-
Bauxite
-
Brushed Gunmetal
-
Magnetite
-
Brushed Carbon
-
Tricorne Black™
-
Oil Rubbed Bronze
-
Mosaic Rust
-
Copper Oxide™
-
Rustic Galvanized
-
Blackened Dull Steel™
-
Native Black Ore™
-
Aged Patina Copper
-
Speckled Aged Copper
-
Western Rust
-
Cor-Ten AZP® Raw
-
Ferrous Oxide™
-
Stable Redox™
-
Copper-Ten® Raw
-
Vintage®
-
Rustic Rawhide®
-
Reclaimed Timber
-
English Walnut
Non-Painted
-
Bonderized (Paint Grip)
-
Rezibond®
-
Electro-Galvanized (Paint Lock)
-
Galvannealed
-
Cold Rolled Bare Steel
-
A606-4 (Corten)
-
Hot Rolled Steel
-
Diamond Tread Plate
-
-
Natural Zinc
-
Lead Coated Copper
-
Natural Copper (many finishes)
-
Hammered Copper
-
Mill Finished Aluminum
-
Clear Anodized Aluminum
-
Batch Anodized Aluminum
-
Architectural Copper
-
304 Stainless Steel no. 2b
-
304 Stainless Steel no. 4
-
Galvalume® Plus
Download Center
Product Info
Accessories
Under X Underlayment
Fasteners (Metal to Wood)
#10 HWH 1/4″ Micro-Bit KiwikSeal WoodBinder
#10 CHWH 5/16″ Micro-Bit ZXL WoodBinder
CHWH 5/16″ Micro-Bit ZXL WoodBinder
Closures & Venting
Pipe Flashings
Sealants & Tapes
Color Guides
Warranty Info
Technical Info (TIS)
Sure Lock ML200 Double Lock Tech Sheet
