PBR Panel
PBR (Purlin Bearing Rib) Structural Panels are one of the toughest and most economical commercial panels available. PBR Panels were designed for low pitched roofing (as low as 1/2:12 pitch – using proper butyl caulk Sealant) to steep pitched roofing. PBR Metal Roofing – Steel Roofing Panels can span open purlins up to 60″ or be installed on a solid substrate. PBR Panels are ideal for Agricultural and Commercial Building Projects of all types, including but not limited to: Roofing, Walls, Pole Barns, Shops, Barns, Steel Buildings, Interior Wall Panels and Fencing. Our standard color offering uses Grade 80 High Tensile Steel for extreme strength and has a Galvalume® substrate and SMP (Silicone Modified Polyester) paint with an available 40 Year Limited Warranty.
Highlights
- Highest Quality Materials Used
- Proven Reliability and Strength
- Easy Installation
- Exposed Fasteners
- Open Purlin System up to 60″ span (check load restrictions)
- Up to 40 Year Paint Warranty Available
- SMP High Tensile 26ga Grade 80 Steel (80,000ksi)(Siliconized Modified Polyester Paint)
- Kynar 500®/Hylar 5000®/PVDF Painted Steel Available in 26ga & 24ga Grade 50 Steel (50,000ksi)
- Manufactured in Rigby, Idaho
- Please refer to PBR Structural Panel Details Section to see all finishes and gauges available.
- Please refer to PBR Structural Panel Details Section for Specifications.
Details
Industry Uses
Residential
Post Frame
Agricultural
Light Commercial
Commercial
Industrial
Applications
Roofing
Siding
Interior
Soffit (non-vented)
Fascia
Fencing
Features
Rib Height 1 1/4″
Rib Spacing 12″ on Center
Coverage 36″ wide
Recommended Minimum Slope 1/2:12 Pitch (using proper butyl caulk)
Installation
Exposed Fastening System
Solid Substrate
Open Purlin System up to 60″ span (check load restrictions)
Gauges Available
Standard Gauge(s): 26ga
Optional Gauge(s): 24ga, 22ga (22ga is Perforated Galvanized Only)
Panel Lengths
2’4″ to 63’0″
Standard Finish
SMP (Siliconized Modified Polyester)
Optional Finishes
Kynar 500®/Hylar 5000®/PVDF
Kynar 500®/Hylar 5000®/PVDF Metallic
Galvalume®
Galvanized
Cold Rolled
Bonderized
Perforated Galvanized
Warranties
SMP up to 40 year Paint Warranty*
Kynar 500® up to 35 year Paint Warranty
Color Selection
Grade 50 Standard 22ga
Non Painted
Grade 50 Standard 22ga Select
Grade 50 Standard 24ga
Economy
Grade 50 Standard 24ga Select
Grade 50 Standard 24ga Low Gloss
-
-
-
-
Gloss Black
-
Rawhide 26ga
Select Rawhide Finishes
Grade 50 Standard 26ga
Non-Painted
Premium
Grade 80 Standard 28ga
Low Gloss
-
Gloss Black
-
-
-
-
