Industry Uses

Residential

Post Frame

Agricultural

Light Commercial

Commercial

Industrial



Applications

Roofing

Siding

Interior

Fascia

Fencing



Features

Rib Height 1 1/2″

Rib Spacing 9″ to 19 1/4″ on Center

Fixed Clips

Coverage 9″ to 19 1/4″” on Center

Recommended Minimum Slope 1 1/2:12 Pitch



Installation

Concealed Fastening System

Solid Substrate

Open Purlin System up to 24″ Span*



Gauges Available

Standard Gauge(s): 24ga

Optional Gauge(s): 22ga

Aluminum: .032

Pure Copper: 16oz, 20oz



Panel Lengths

3′ to 150′



Standard Finish

Kynar 500®/Hylar 5000®/PVDF



Optional Finishes

Kynar 500®/Hylar 5000®/PVDF Metallic

Galvalume®

Galvanized

Cold Rolled

Bonderized

Aluminum

Pure Copper



Warranties

SMP up to 40 year Paint Warranty*

Kynar 500® up to 35 year Paint Warranty*

*Oil Canning is not a cause for rejection
