Sure Snap SL175 Wall System

Concealed Fastening Wall System

Sure Snap SL175

The 1-3/4″ Snap Seam Panel is a Standing Seam Metal Roof Panel that has all fasteners concealed for a sleek look and most importantly incredible strength and weather resistance. The 1-3/4″ Snap Seam Panel can be installed over a solid substrate or open purlin system. This Metal Roofing – Steel Roofing Panel uses a clip system that allows the panel to float for the expansion and contraction of the steel. When using an 18ga Clip, this panel has incredible wind resistance. This Standing Seam Metal Roof Panel comes in a variety of standard widths and colors, but can be customized to the needs that you are looking for. This panel can be roll formed on site or at our facility in Rigby, Idaho. Rollforming on site can help reduce shipping costs and damage to the panels in the shipping process.

Highlights

Highest Quality Materials Used
Proven Reliability and Strength
Concealed Fasteners and Contraction Clip System
Custom Widths available from 8″ to 24″
Recommended Minimum Slope 2:12 Pitch
Incredible Wind Resistance using 18ga Clips
Does not require a seamer for installation.
Protective Film can be applied prior to rollforming for added protection.
An optional Hot Melt In-seam Sealant is available.
With or Without Striations or Box Ribs
Up to 40 Year Limited Paint Warranty Available
Watertight Warranty Available
SMP 26ga Grade 50 Steel (50,000psi)(Siliconized Modified Polyester Paint)
Kynar 500®/Hylar 5000®/PVDF Painted Steel Available in 26ga & 24ga, 22ga Grade 50 (50,000psi)
Manufactured in Rigby, Idaho or on Job Site
Please refer to 1-3/4” Snap Seam Details Section to see optional finishes and gauges available.
Please refer to 1-3/4” Snap Seam Details Section for Specifications.
Oil Canning is not cause for rejection.
