2.75 x 3/4 Corrugated Panel

The 3/4” Corrugated Panel is an exposed fastener Metal Roofing – Steel Roofing and/or Metal Siding – Steel Siding panel. This panel offers the versatility of being used in both vertical and horizontal applications. This Corrugated Roofing – Corrugated Siding panel gives the look of an old time and/or modern roofing application.



Highlights

  • Highest Quality Materials Used
  • Rib Spacing is 2.75” on center
  • Rib Height is 3/4” on 2.75” Centers with Anti-Siphon Groove
  • Variable Coverage (dependent on material used and/or if used for roofing or siding.)
  • 1:12 Pitch or greater with butyl tape sealant & recommended self-adhered underlayment covering entire substrate3:12 Pitch or greater (optional: recommended butyl tape sealant)
  • Up to 40 Year Limited Paint Warranty Available
  • Please refer to 3/4” Corrugated Panel Highlights Section to see all finishes and gauges available.
  • Please refer to 3/4” Corrugated Panel Highlights for Specifications.

Details

Industry Uses

Residential

Post Frame

Agricultural

Light Commercial

Commercial

Industrial



Applications

Roofing

Wall

Interior

Soffit (non-vented)

Fascia

Ceiling



Features

Rib Height 3/4″

Rib Spacing 2.75″

Variable Coverage



Installation

Exposed Fastening System

Solid Substrate

Open Purlin System up to 60″ span (check load restrictions)



Gauges Available

Standard Gauge(s): 26ga

Optional Gauge(s): 29ga, 28ga



Panel Lengths

1″ to 63’0″



Standard Finish

SMP (Siliconized Modified Polyester)

Optional Finishes

Galvalume®

Galvanized



Warranties

SMP up to 40 year Paint Warranty*

Color Selection

Grade 80 Standard 26ga
Grade 80 Standard 28ga Economy
Grade 80 Standard 28ga Textured Finishes
Grade 80 Standard 28ga Premium



Grade 80 Standard 28ga Low Gloss
