Sure Grip Board & Batten™
The Architectural Sure Grip Board & Batten™ panel profile is a clean designed panel that is know for its classic board & batten look. This panel can be fabricated in a 26ga or 24ga. thickness. Another great option for this panel is the ability to run On-Site for those longer panels that are difficult to handle. Rollforming on-site can help reduce shipping costs and damage to the panels in the shipping process. This wall panel can be installed Vertically or Horizontally. For 8” Board and Batten and for 22ga thicknesses, refer to the Sure Grip Board & Batten HD™ panel.
Highlights
- Wall and Interior Applications
- Proven Reliability and Strength
- Standard Widths: 8”, 121/2”, 141/2, 161/2“, 201/2” (optional) custom widths available 10” to 25¼ *available widths vary from finish to finish.
- Concealed Fastening with Built-In Fastening Strip
- SMP 26ga Grade 50 Steel (50,000psi)(Siliconized Modified Polyester Paint)
- 26 or 24ga High Quality Grade D Steel (yield strength of 50,000 psi) (optional) 16oz, 20oz Copper, 0.7mm, 0.8mm Zinc, 0.032” Aluminum
- Manufactured in Rigby, Idaho or on Job-Site Oil Canning is not cause for rejection.
Details
Industry Uses
Residential
Post Frame
Agricultural
Light Commercial
Commercial
Industrial
Applications
Wall
Interior
Features
Rib Height: 3/4” Tall
Rib Concealed Fastening with Built-In Fastening Strip
Coverage
Standard Widths: 8”, 121/2”, 141/2, 161/2“, 201/2” (optional) custom widths available 10” to 25¼ *available widths vary from finish to finish.
Installation
Concealed Fastening System
Solid/Open Purlin System
Gauges Available
Standard Gauge(s) 26ga, 24ga
Panel Lengths
Maximum Length of 48’ 0” Minimum Length of 3’0” (contact representative for special consideration on panels over 10’0”)
Standard Finish
Fluropon® by Sherwin-Williams® PVDF (Kynar 500® or Hylar 5000®) Fluropon® by Sherwin-Williams® PVDF 3 Coat (Kynar 500® or Hylar 5000®) WeatherXL™ SMP by Sherwin-Williams® (Silicone Modified Polyester) Super Dynapon by Sherwin-Williams® (ceramic pigment polyester coating) AZ55 Galvalume® with Acrylic Coating
Galvalume® Galvanized Warranties SMP up to 40 year Paint Warranty*
Color Selection
Download Center
Product Info
Accessories
Under X Underlayment
Fasteners (Metal to Wood)
#10 HWH 1/4″ Micro-Bit KiwikSeal WoodBinder
#10 CHWH 5/16″ Micro-Bit ZXL WoodBinder
CHWH 5/16″ Micro-Bit ZXL WoodBinder
Closures & Venting
Pipe Flashings
Sealants & Tapes
